Description of expanded metal machine:

The (expanded mesh machinery; expande metal mesh machine; expanded metal lath machine) High Quality Expanded Metal Mesh Machine belongs to medium size machine. The machine can make expanded metal mesh width up to 1300mm, and the mesh thickness up to 3mm. The running speed of this machine is 110 times/min.

It is suitable for the material such as low carbon steel sheet, aluminum sheet, stainless steel sheet, aluminum magnesium alloy sheet, copper sheet, Nickel sheet. Finished product application. The light expanded metal mesh widely use for filter, stereo shield, decoration, arts and crafts, covering screen for first class sound case etc.

Main technical parameters:

Model: BXE--4-1300
Normal pressure: 60 Tons;
Thickness of material: ≤4mm;
Width of material: ≤1300mm;
Distance of feed: 0-6mm;
Stroke per min: 110 strokes / min;
Motor power: 11KW;
Rotation speed of motor: 1480r/min;
Weight: about 6 tons;
Overall dimension (L*W*H): 3400*3400*2350mm

Typical application of expanded metal mesh:
